Dynatek Direct Coil On Plug Stick Coils
Are you looking to increase horsepower with your High Compression, Nitrous or Turbo Motorcycle? Dyna Performance Electronics has what you need!
Dynatek would like to announce the release of our new High Performance Dynatek Coil-on-Plug (DCOP) replacement coils. Like all Dynatek High Performance Coils the DCOP offers increased spark energy as well as a factory replacement fit.
Features:
- Increased Spark Voltage
- Factory Reach and Dust Seals
- Factory Connectors
Specifications:
- Primary resistance: 0.85 ohms
- Primary inductance: 2.25 mH
- Secondary resistance: 4.95K ohms
- Secondary inductance: 12.1 H
- Test voltage: 13.8V
- Dwell time to achieve test current: 1.3ms=4.5A, 2.0ms=6.8A
- Secondary available voltage: 24.8Kv @ 4.5A, 32.8Kv @ 6.8A
- Secondary peak gap current: 64.4mA @ 4.5A, 94.8mA @ 6.8A
- Spark duration: 0.835ms @ 4.5A, 1.045ms @ 6.8A
Available for the Following Models:
| Kawasaki | Suzuki | Yamaha |
| ZX14 (06-15) | GSX1300R Hayabusa (99-15) | YZF-R1 (09-14) |
| ZX10R (11-15) | B-King (all) | |
| ZX10R (04-10) | ||
| ZX6R (09-15) | ||
| ZG1400 Concours (08-15) | ||
| ZR1000/ZX1000 Ninja (11-12) | ||
| EX650/Versys 650 (10-12) |
