Product Description
This system will make 550 HP on race fuel and is designed for the person who is not planning on building an all out race bike. It is similar to the Race kit, but uses a 2 " up-pipe that goes through the ram air tube hole. You do not have to cut a frame cross member for the up-pipe nor do you need to relocate your cooling fan.
Hayabusa Race Turbo Kit:
- Garret GT 35-R
- 44 mm V-band tial wastegate
- 50 mm tial blow off valve
- 3" stainless steel race dump pipe
- 304 grade stainless steel header and flanges
- Braided oil feed line and fittings
- Oil return line and fittings
- New in-line fuel pump
- Fuel pressure regulator
- Fuel lines for the fuel system
- Billet primary fuel rail with larger injectors
- Billet air box
- 2" up-pipe with V-Band clamp and o-ring
- Oil block off plates
- Crankcase vent filter
- K&N air filter
- All vacuum lines, connectors, hose clamps, and fittings are prelabeled for easy installation
- Installation instructions are provided on CD along with ECU Editor Bin Files.
*Tech Article: Suzuki Hayabusa Turbo Engine Build List
