Product Description
Features:
- Machined from 2618 T6 high tensile forged aluminum
- Dome/Dish features smooth flowing radii and require no deburring or preparation
- JE designs are specifically engineered for extreme applications including professional competition
- Pins, pin fitment, wire locks and rings included
Suzuki GSXR1000 09-11
Std Bore: 74.5mm
| Piston Kit # |
Disp. | Bore Size |
Over Size |
Comp Ratio |
Gram Wt (g) |
Skirt Style |
Ring # | Pin # | Lock # | |||
 |
||||||||||||
| 284700 | 999cc | 74.5mm | STD | 10.1:1 | 180 | FSR | XA7450 | 591-1650-14-PTC | 591-040-MW | |||
|
||||||||||||
| 284701 | 999cc | 74.5mm | STD | 13.8:1 | 171 | FSR | XA7450 | 591-1650-14-PTC | 591-040-MW | |||
|
||||||||||||
| 284702 | 999cc | 76.5mm | +2mm | 13.8:1 | 183 | FSR | XG7650 | 591-1650-14-PTC | 591-040-MW | |||
Suzuki GSXR1000 05-08
Std Bore: 73.4mm
| Piston Kit # |
Disp. | Bore Size |
Over Size |
Comp Ratio |
Gram Wt (g) |
Skirt Style |
Ring # | Pin # | Lock # | |||
|
||||||||||||
| 254555* | 998cc | 73.4mm | STD | 10.1:1 | 179 | FSR | OEM (NOT INCL) | 591-1650-14-PTC | 591-040-MW | |||
|
||||||||||||
| 247628 | 998cc | 73.4mm | STD | 13.8:1 | 158 | FSR | OEM (NOT INCL) | 591-1650-14-PTC | 591-040-MW | |||
|
||||||||||||
| 247629 | 1043cc | 75mm | +1.6mm | 13.5:1 | 167 | FSR | XG7500 | 591-1650-14-PTC | 591-040-MW | |||
|
||||||||||||
| 247631 | 1070cc | 76mm | +2.6mm | 13.5:1 | 173 | FSR | XG7600 | 591-1650-14-PTC | 591-040-MW | |||
Suzuki GSXR1000 01-04
Std Bore: 73mm
| Piston Kit # |
Disp. | Bore Size |
Over Size |
Comp Ratio |
Gram Wt (g) |
Skirt Style |
Ring # | Pin # | Lock # | |||
|
||||||||||||
| 222105* | 988cc | 73mm | STD | 9.8:1 | 182 | Round | XA7300 | 630-2050-14-95C | 630-050-MW | |||
|
||||||||||||
| 215817 | 988cc | 73mm | STD | 13.5:1 | 156 | FSR | XA7300 | 630-1650-14-PTC | 630-050-MW | |||
|
||||||||||||
| 213919 | 1042cc | 75mm | +2mm | 13.5:1 | 162 | FSR | XG7500 | 630-1650-14-PTC | 630-050-MW | |||
|
||||||||||||
| 192322 | 1070cc | 76mm | +3mm | 13.5:1 | 180 | Round | XG7600 | 630-2050-14-95C | 630-050-MW | |||
|
||||||||||||
| 221407 | 1070cc | 76mm | +3mm | 13.5:1 | 177 | FSR | XG7600 | 630-1650-14-PTC | 630-050-MW | |||
*Must use .060" Head Gasket
