Product Description
Features:
- Machined from 2618 T6 high tensile forged aluminum
- Dome/Dish features smooth flowing radii and require no deburring or preparation
- JE designs are specifically engineered for extreme applications including professional competition
- Pins, pin fitment, wire locks and rings included
Kawasaki ZX10R 08-15
Std Bore: 76mm
| Piston Kit # |
Disp. | Bore Size |
Over Size |
Comp Ratio |
Gram Wt (g) |
Skirt Style |
Ring # | Pin # | Lock # | |||
 |
||||||||||||
| 284718 | 998cc | 76mm | STD | 13.5:1 | 178 | FSR | XG7600 | 669-1650-14-PTC | 669-050-MW | |||
|
||||||||||||
| 284720 | 1078cc | 79mm | +3mm | 13.5:1 | 186 | FSR | XG7900 | 669-1650-14-PTC | 669-050-MW | |||
|
||||||||||||
| 284719 | 1051cc | 78mm | +2mm | 13.5:1 | 192 | FSR | XG7800 | 669-1650-14-PTC | 669-050-MW | |||
Kawasaki ZX10R 04-07
Std Bore: 76mm
| Piston Kit # |
Disp. | Bore Size |
Over Size |
Comp Ratio |
Gram Wt (g) |
Skirt Style |
Ring # | Pin # | Lock # | |||
|
||||||||||||
| 222111 | 998cc | 76mm | STD | 13.5:1 | 175 | FSR | XG7600 | 669-1650-14-PTC | 669-050-MW | |||
|
||||||||||||
| 222112 | 1051cc | 78mm | +2mm | 13.5:1 | 183 | FSR | XG7800 | 669-1650-14-PTC | 669-050-MW | |||
|
||||||||||||
| 247931 | 1078cc | 79mm | +3mm | 13.5:1 | 185 | FSR | XG7900 | 669-1650-14-PTC | 669-050-MW | |||
